Regular Smart

  • Regular Smart Regular Smart
  • Regular Smart Regular Smart
  • Regular Smart Regular Smart
  • Regular Smart Regular Smart

  • Suitable for (Sand) light & medium soil
  • Designed to perform dry as well as wet cultivation
  • Produces fine seed bed with one or two passes before or after rains

MODEL SRT-4 SRT-5 SRT-5.5 SRT-6 SRT-6.5 SRT-7
Overall Length (mm) 1414 1760 1889 2026 2139 2259
Overall Width (mm) 812
Overall Height (mm) 1135
Tilling Width (mm / inch) 1269 / 50 1615 / 63.6 1744 / 68.6 1881 / 74 1994 / 78.5 2114 / 83.2
Tractor Power HP 30-45 35-50 40-55 45-60 50-65 55-70
Tractor Power Kw 22-33 26-37 30-41 34-45 37-48 41-52
3-Point Hitch Type Cat – II
Frame Off-set (mm / inch) 0 86 / 3.5 0 30 / 1.2 27 / 1 0
No. of Tines (L-80×7) 30 36 39 42 45 48
No. of Tines (C/J-40×7) 48 60 66 72 78 84
No. of Tines (J-40×7)
(Bracket Type Rotor)
36 44 48 52 56 60
Standard Tine Construction Curved / Square
Transmission Type Gear / Chain
Max. Working Depth (mm / inch) 203 / 8
Rotor Tube Diameter (mm / inch) 89 / 3.5
Rotor Swing Diameter (mm / inch) 480 / 18.9
Driveline Safety Device Shear Bolt / Slip Clutch
Weight (Kg / lbs) 353 / 778 388 / 856 403 / 890 419 / 923 435 / 959 448 / 989

Rotor RPM chart

Series Input RPM Gear Box Spur Gear 1 Spur Gear 2 Rotor Speed
Regular
Smart
(GD)
540 SS 193
MS 17 19 173
18 18 193
19 17 216
20 16 241
1000 MS 12 24 179
13 23 202
14 22 228
Regular
Smart
(GD)
540 SS 201
MS 17 19 179
18 18 201
19 17 224
1000 MS 12 24 186
13 23 210
14 22 236

* The Company reserves absolute rights to modify the specifications of machine and components therein without any prior notice.
